Sense Thermo Instruments India Pvt. Ltd. is reputed manufacturers, suppliers, and exporters of Thermocouple for Muffle Furnace in India, Gurgaon, Raipur, Mumbai, Navi Mumbai, PCMC, Pimpri Chinchwad, Khopoli, Patalganga, Pen, Taloja, Rabale, Turbhe, Ambernath, Boisar, Chennai, Coimbatore, Hyderabad, Aurangabad, Chakan, Ranjangaon, Sanaswadi, Shikrapur, Roha, Satara, Nagpur, Nashik, Manesar. We are offering high quality of thermocouple for a muffle furnace—muffle furnace thermocouple in short—is a temperature sensory device highly specialized to withstand the extreme heating conditions manifested in industrial and laboratory furnaces.
This thermocouple is a principal component of almost any system carrying out thermal processing at elevated temperatures, since accurate and reliable temperature measurements provided by such instruments are essential to mimic appropriate material properties, quality control, and energy efficiency.
One of the ovens high in temperature is the muffle furnace used for materials testing, ashing, sintering, heat treatment, and various other industrial or laboratory applications. Preventing access to direct flame or combustion gas action, it provides a clean, controlled environment to the specimen. Such furnaces often reach above 1200°C, thereby requiring extremely robust materials and components, and a strong thermocouple with good responsiveness.
| Parameter | Specification |
|---|---|
| Temperature Range | Up to 1200°C Type K, 1600°C Type S/R, 1800°C Type B |
| Sheath Material | High-purity recrystallized alumina / Inconel / SS 310 |
| Sheath Diameter | 6 mm / 8 mm / 10 mm / 12 mm customizable |
| Sheath Length | 200 mm – 1000 mm custom as per furnace size |
| Insulation | Ceramic bead or compacted MgO |
| Accuracy Class | Class 1 as per IEC 60584 standards |
| Output Signal | Millivolt (mV) – direct thermoelectric output |
| Response Time | 2 – 5 seconds depending on configuration |
| Mounting Style | Flange / Threaded / Adjustable compression fitting |
| Cable Type | Compensating / extension cable with ceramic or fiberglass insulation |
A thermocouple is a temperature sensor made of two dissimilar metals that create a voltaic potential with heat. Thermocouples in a muffle furnace establish thermal uniformity within the furnace or avoid overheating or under heating. This cannot happen without having a reliable and accurate thermocouple in place, which otherwise would be the biggest culprit behind a thermal process being worthless, giving inconsistent results, or even damaging the materials or the furnace itself.
We are leading muffle furnace thermocouple suppliers and exporters, below are the applications of thermocouple in diverse industries and processes:
Sense Thermo Instruments India Pvt. Ltd. is leading manufacturers, suppliers, and exporters of Thermocouple for Muffle Furnace. Every product we make or design is of a specialized and premium-grade muffle furnace thermocouples, having accurate and durable and temperature stable characteristics. With several years of industry experience, we provide customized solutions for any other specific furnace needs you may have. We produce thermocouples of certified material and perform quality checks on them at extreme conditions. Precision, reliability, and service are just a few words that come with using us.
