Thermocouple for Fluid Bed Furnace in India by Sense Thermo Instruments

Sense Thermo Instruments India pvt. Ltd. is trusted Thermocouple For Fluid Bed Furnace manufactures, suppliers, and exporters in India, Khopoli, Patalganga, Pen, Taloja, Rabale, Turbhe, Ambernath, Chakan, Gurgaon, Raipur, Mumbai, Navi Mumbai, PCMC, Pimpri Chinchwad Ranjangaon, Nashik, Hyderabad, Sanaswadi, Shikrapur, Roha, Satara, Nagpur,and Aurangabad Manesar, Boisar, Chennai, Coimbatore. We offer the best quality. Fluidized bed furnaces embody the most important thermal characteristics concerning the efficiency of heat transfer and temperature uniformity, power generation, chemical processing, metallurgy, performance, and safety temperature monitoring. Mostly, they operate in ranges greater than 600 degrees Celsius to more than 750 degrees Celsius so temperature monitoring is very important in terms of performance and safety. The properties these thermocouples have for application in fluidized bed furnaces are precision and durability.


What is a Thermocouple for Fluidized Bed Furnaces?

A thermocouple is a temperature measurement sensor that typically consists of two dissimilar thermoelectric materials and, typically, two junctions in sufficient proximity on the test object so that one is exposed to the measurement environment while the other is in a controlled environment. These thermocouples easily withstand abrasive flowing medium or high corrosive gases and high temperatures in a process and environment, thus providing accurate temperature readings for process and safety.


Technical Specifications of Thermocouple For Fluid Bed Furnace:

Parameter Details
Temperature Range 0°C to 1600°C varies by thermocouple type
Thermocouple Types Type J (-40°C to 750°C), Type K (-200°C to 1300°C)
Sheath Materials SS 304, SS 310, SS 316, Inconel 600
Junction Configurations Grounded, Ungrounded, Exposed
Sheath Diameters 3 mm, 6 mm, 8 mm
Protection Tube O.D. 6 mm, 12 mm, 16 mm, 22 mm, 25 mm
Connection Heads Cast Aluminum Standard, Mini, Flameproof
Output Options 4–20 mA Transmitter, Standard Thermocouple Output
Mounting Threads 1/2" NPT, 3/4" NPT

Key Features of Thermocouple for Fluid Bed Furnace

Refers to the below different features of the furnace, such as:

  • High-Temperature Resistance: Up to 1700°C for many applications across industries.
  • Durable Design: High-strength sheath materials like SS 304, SS 310, SS 316, and Inconel 600 are built to resist corrosion and wear.
  • Versatile Junction Types: All types of junction configurations are available to satisfy different applications with respect to response time versus durability.
  • Customization: Any design is possible, including sheath diameters and lengths, mounting options, etc., to fit around different furnace configurations.

Applications of Thermocouple for Fluid Bed Furnace:

We are the top thermocouple for fluid bed furnace suppliers and exporters in India. These applications are used in various industries.

  • Thermal Power: Combustion temperatures in circulating fluidized bed (CFB) boilers monitored for improved efficiency and reduced emissions.
  • Chemical Processing: Control temperature during catalytic cracking and gasification - better product quality due to efficiency.
  • Metallurgy: Uniformity of temperature environments in roasting and sintering of minerals to desired properties.
  • Research and Development: The purpose is to measure the temperature consistently for optimizing the process in pilot plants and testing furnaces.

Sense Thermo Instruments India pvt. Ltd. is a trusted Thermocouple for Fluid Bed Furnace manufacturers, suppliers, and exporters in India. We manufacture high-end, high-efficiency thermocouples that can measure temperatures in fluidized bed furnace applications. Our products utilize high-end materials as well as progressive engineering for the most rigorous of environments. We are steadfast in offering quality assurance, customization, and customer support for your temperature-sensing solutions to help enhance the efficiency of your operations.
